AnyMark Documentation

AnyMark Documentation

What is AnyMark?

AnyMark is a Markdown parser written in PHP.

Should I use AnyMark?

AnyMark was written to be customizable. It was not written to be the fastest Markdown parser available. PHPMarkdown is much faster and is recommended if speed is your primary concern.

How can I use AnyMark?

Installation

AnyMark can be installed through Composer. The composer.json should contain at least the following:

{
    "require": {
        "anymark/anymark": "0.1.*"
    }
}

Manual installation is also possible. AnyMark can be downloaded from github. It depends on Fjor which should be autoloaded too (see the Fjor manual).

Library Use

Instatiating AnyMark is a two step procedure.

$fjor = \AnyMark\AnyMark::setup();

This creates an instance of Fjor and wires the dependencies. You can change these dependencies. Next create an instance of AnyMark:

$anyMark = $fjor->get('AnyMark\\AnyMark');

Parsing a Markdown document is simple:

$domDocument = $anyMark->parse('== AnyMark ==');

It will return a \DomDocument. If you want to save this to XML as a string call

$xmlString = $anyMark->saveXml($domDocument);

You could call \DomDocument::saveXml() but this could lead to unwanted results. The reason is that loading the text into the Dom translated encoded characters like & (this becoming &) and this is done also while calling \DomDocument::saveXml(), being one time too many.

Custom Patterns

What patterns, the order in which the patterns are handled and its relations are defined in an ini file. The default ini file can be found in the AnyMark directory. AnyMark accepts a custom ini file this way:

$anyMark->setPatternsIni($myCustomIniFile);

Syntax

The markup follows mostly regular Markdown markup with but with some differences.

Handling of special characters

As in the Markdown implementation the ampersand (&), greater than sign (>) and lesser than sign (>) are automatically converted to entities so you don't have to worry about that when you are writing. The ampersand is not replaced when it is part of an entity (except in code blocks).

When you like to avoid that a character triggers a special meaning you can escape it with a backslash.

This \*word\* won't be rendered as <em>word</em> but as *word*.

Raw HTML

Not everything is possible with the simple syntax rules AnyMark uses. If you would need to you can add raw HTML to the text.

A paragraph needs a blank line before and after. That means that you can add HTML like this

A short paragraph.

<div>

A paragraph withing manually added tags.

</div>

Note the blank lines.

The paragraph will be placed within the div element.

If the pattern is indented, as when you are writing a paragraph in a list item, the tags that surround it should also be indented.

* item a
* Item b has an extra paragraph.

  <div>

  This paragraph is within div tags that need to be indented.

  </div>

Headers

Atx style headers are headers preceded by one or more dash signs. The number of them determines its level.

## level 2 header

Setext style headers are supported too but are made a bit more powerful. They are assigned a level in order of appearance. The first used markup will be used as a level 1 header throughout the document.

Allowed signs to mark headers are: -=+*^#. At least three such signs must be used and they can appear before or before and after the header text.

Some examples will make this clear:

---
a header
---

=_=_=_=
another header
*******

The first three signs are what counts. Eg the following two will have the same level:

---***
a header
---***

---+++
same level header
---+++

Different than with regular Markdown output is that AnyMark will generate id's based upone the header text. It will translate to something like this:

<h1 id="a-header">a header</a>

First all white spaces are converted to -. Then all characters that are not alfanumeric, underscore, dash or point are removed. After this everything up to the first letter is removed. All inspired by Pandoc.

When several headers have the same id a number suffix is added to distinguish them.

Paragraphs

A paragraph is formed by text preceded and followed by a blank line.

This is a paragraph. It is followed by a blank line.

This is also a paragraph. It is preceded by a blank line. It is not followed by a
blank line because it is the end of the virtual file.

Indentation can be used to make the document more readable.

In Markdown a paragraph can be immediately followed by a header or blockquote:

This is a paragraph.
# header

In my implementation this is not possible. A paragraph is only ended with a blank line or indented text:

This is a paragraph.
  # header indented

One reason is that this makes it less easy to create unexpected headers:

My favorite track on the cd is track
#8.

Code

Code is preceded by the word 'CODE:' with the actual code following on the second line. Both are indented. The code block must be indented in respect to the previous lines.

This is a regular paragraph with samples of code blocks:

    CODE:
    Note the 'CODE:' word. It is followed by the actual code.

    CODE:

        White space is possible.

    CODE: This is another possibility.

This is the next paragraph.

The code block must be preceded and followed by a blank line. Note that the 'code' word is case insensitive.

Another option is to write code between two lines of three tildes.

this is also treated as code

Actually, what is after those three tildes doesn't matter, so you could just as well write:

this is also treated as code

This type of code doesn't need to be indented. When you need to write three tildes as code you'll have to indent it though:

A short paragraph.

~~~ code ~~~
    ~~~
    meta code example
    ~~~
~~~~~~~~~~~~

Another Short paragraph.

Inline code is also possible with backticks:

You could write `$this->foo` for example.

The standard option is to write code by indenting text four spaces or a tab:

A paragraph.

    This is code.

The next paragraph.

Note

Notes can be created as follows:

!NOTE This is a note.

    This sentence is still
part of the note.

This sentence is outside the note.

The word 'note' is case insensitive. A note block is ended with a blank line followed by text equally or less indented.

blockquote

Blockquote are quoted text preceded by >.

> this is a blockquote
> continues on the next line

Lazy quoting is also possible.

> this is a blockquote
continues on the next line

Blockquotes can contain other markup.

> this is a blockquote
>
> > within a blockquote
> > another blockquote
>
> notice the blank lines

Lists

For unordered lists you can use *, + or -.

+ an item
+ other item

For ordered lists use a number followed by a dot.

1. First item
2. Second item

The actual numbers used do not influence order. Instead of numbers you can also use the hash sign followed by a dot (inspired by Pandoc.

#. First item
#. Second item

A list needs a blank line before and after it if the list item starts unindented. If you use one to three spaces a blank line is not necessary.

A paragraph.
 * a list item indented one space

Nested lists are possible if you follow the rule of either a blank line or space indentation.

* item
* item with a sublist

    * item in sublist
    * other item in sublist

* item in main list

This is a difference with Markdown which requires only a blank line in the first level of the list.

Horizontal rules

Three or more hyphens, underscores or asterisks on its own line. Spacing is allowed but take not that if you start the line with four or more spaces it will become code.

* * *
---
 _ __

All three will produce a horizontal rule.

Links

An url between < and > is automatically converted to a hyperlink. Thus

<http://www.mysite.com>

becomes

<a href="http://www.mysite.com">http://www.mysite.com</a>

Full links contain anchore text, the url and optional title text:

(anchor text)[url "title text"]

Different than with pure Markdown syntax the anchore text and url can be placed on different lines.

This is also possible for a link: (anchor text)
[url "title text"].

A link reference can be used to place the actual url somewhere else in your text. Note that single brackets are used. The link definition can contain the title attribute:

This is a [link] [1] in text.

The link definition can be placed somewhere else on its own line,
optionally indented one to three spaces.

[1]: http://example.com "title"

Images

The syntax for images follows the Markdownimplementation. The two styles are inline and reference.

Inline images are written as follows:

![alternate text](link/to/image "optional title")

The title can be between single and double quotes.

Reference style images have the following syntax:

![alternate text][link id]

The link id syntax is the same as with regular links. You can place the link definition anywhere in the text.

[link id]: link/to/image "optional title"

Email

An automatic email link is created by placing the email address between a lesser than and greater than sign.

Mail me at my <mail@example.com>.

The regular link syntax allows to create an email link with anchor text.

This is [my email](mailto:mail@example.com).

Italic, emphasized and important text

Words can be italicized by wrapping them between underscores. Underscores in words are left as is. Underscores that span more than one word are allowed.

A couple of _italicized words_.

Becomes

A couple of <i>italicized words</i>.

Emphasized text is placed between asterisks:

Emphasized text is placed *between* asterisks.

Becomes

Emphasized text is placed <em>between</em> asterisks.

Important text is achieved by putting words between double asterisks:

A sentence with **important** text.

Becomes

A sentence with <strong>important</strong> text.

!Note: Importance is chosen instead of strong importance to reflect the change coming with HTML5. See the section on changed elements.

There is a difference between this implementation and that of Markdown. Italicized text doesn't exist in Markdown. The syntax I use for emphasized text in Markdown (`_underscore_`) produces italicized text.

Newlines

Newlines can be inserted by adding a double space at the end of the line. This follows Markdown convention. Writing documentation is a different context from writing forum or blog posts. I think there are less cases in documentation where having a hard line break would be beneficial. More technically oriented users will also have less problem adoption this, although admittedly it is counterintuitive.

I've considered adopting the suggestion in the comments of allowing hard line breaks in top-level paragraphs. But it adds complexity in the rules.

Readability should be the prime goal and I believe that for writing documentation using two spaces has the most benefits in that regard.

Definition lists

A term followed by description followed by a colon. Multiple terms can share the same description. A term can have multiple descriptions if they are separated by a tilde. Here's an example:

term a:
term b:
    ~explanation of term a and b
    it continues on the next line

    it contains more than one paragraph

    ~alternative explanation
